GELOSO mod. G-301 M - Italy 1955

Receiver Geloso G-301

Receiver Geloso mod. G-301 M (Italy 1955) - Superetherodyne receiver with 6 tubes: UCH81, UF41, UBC41, UL41, DM70, UY41. Receiving bands: 1 AM broadcasting and 4 shortwaves bands. Magnetic-dynamic loudspeaker type Geloso SP100. Plastic case was brown for the "M" version. "Magic Eye" in the front panel center. Power requirements: AC net 110 to 220 Vac. Dimensions: 25x12x15 cm.
Ricevitore Geloso mod. G-301 M (Italia 1955) - Ricevitore supereterodina con sei valvole: UCH81, UF41, UBC41, UL41, DM70, UY41. Bande ricevute 6: Onde medie piu' 4 bande di Onde Corte. Altoparlante magnetodinamico typo Geloso SP100. Mobiletto in plastica che era marrone per la versione "M". Occhio magico nel centro del pannello frontale. Alimentazione da rete 110 - 220 Vca. Dimensioni: 25x12x15 cm.
Click to enlarge Click to enlarge Click to enlarge Click to enlarge
Click to enlarge Click to enlarge Click to enlarge Click to enlarge
Click to enlarge Click to enlarge
